High Temperature Resistant EPDM Rubber Sponge Seal Strip For Automotive
Détails sur le produit:
| Lieu d'origine: | Fabriqué en Chine |
| Nom de marque: | EkkoFlex |
| Certification: | ROHS,REACH |
Conditions de paiement et expédition:
| Quantité de commande min: | 3000㎡ |
|---|---|
| Prix: | $0.8-1.89/㎡ |
| Détails d'emballage: | Poly sac ou personnalisé |
| Délai de livraison: | 7-14 jours de travail |
| Conditions de paiement: | T / t, l / c |
| Capacité d'approvisionnement: | 1000000m par mois |
|
Détail Infomation |
|||
| Nom de produit: | Grande bande de joint d'éponge EPDM à haute température pour l'automobile | Matériel: | Monome éthylène-propylène-diène |
|---|---|---|---|
| Structure cellulaire: | Mousse EPDM à cellules fermées et mousse EPDM à cellules ouvertes | Densité (cellule ouverte): | 95-100kg / m³ |
| Densité (cellule fermée): | 110-150 kg / m³ | Fonctionnalité: | Tampon élastique élevé, résistance à la température, résistance aux flammes |
| application: | Machine domestique; scellé pour l'équipement électronique | Couleur: | Noir |
| Épaisseur: | 1-50 mm | Taille maximale: | 1000 * 2000 * 50 mm |
| Mettre en évidence: | high temperature resistant EPDM rubber seal,automotive EPDM sponge strip,EPDM rubber foam seal strip |
||
Description de produit
High Temperature Resistant EPDM Rubber Sponge Seal Strip For Automotive
Density is a key parameter of EPDM foam, directly affecting its compressibility, resilience, and sealing properties.
- Low-density EPDM foam (0.03-0.1 g/cm³): Typically used in applications requiring lightweight materials, such as cushioning and shock absorption pads in electronic devices. Due to its low density, it offers good compressibility but relatively poor resilience and durability, making it suitable for applications with less stringent sealing requirements.
- Medium-density EPDM foam (0.1-0.3 g/cm³): Widely used in sealing gaskets and waterproof gaskets in electronic devices. Medium-density foam strikes a balance between compressibility and resilience, providing excellent sealing while also offering a certain degree of durability.
- High-density EPDM foam (0.3g/cm³ and above): Suitable for applications requiring high sealing and durability, such as electronic device housing sealing and waterproof joints. High-density foam has excellent resilience and compressive strength, ensuring long-term sealing.
Specification:
EPDM(Closed cell)Physical Properties:
| Name&Model | Color | Density (kg/m³) |
Hardness (Shore C°) |
Tensile Strength (Kpa) |
Elongation (%) |
Compression Deformation (%) |
Tear Strength (kn/m) |
Size(mm) | Remarks |
| EPDM-9016 | Black | 190±15 | 25°±5 | ≥500 | ≥130 | ≤40 | ≥3.0 | 950*1900*40 | |
| EPDM-9015 | Black | 150±15 | 15°±5 | ≥400 | ≥120 | ≤45 | ≥2.0 | 1000*2000*50 | |
| EPDM-9010 | Black | 130±15 | 10°±3 | ≥350 | ≥120 | ≤35 | ≥1.8 | 1000*2000*50 | |
| EPDM-9008 | Black | 110±15 | 8°±3 | ≥350 | ≥120 | ≤35 | ≥1.8 | 1000*2000*50 | |
| EPDM-WS | Black | 150±15 | 15°±5 | ≥400 | ≥120 | ≤40 | ≥2.0 | 1000*2000*50 | Sulfur free |
| EPDM-GBZ | Black | 250-500 | 30°-50° | ≥800 | ≥130 | ≤20 | ≥5.0 | 900*1800*35 | High density |
| EPDM-GYD | Black | 600-700 | 50°-75° | ≥1200 | ≥90 | ≤10 | ≥8.0 | 600*1200*30 | High hardness |
| EPDM-SMP | Black | 300±25 | 18°±5 | ≥500 | ≥150 | ≤25 | ≥2.0 | 400*500*568 | Double sided crust |
EPDM (Open cell) Physical Property:
| Name&Model | Color | Density (kg/m³) |
Tensile Strength (Kpa) |
Elongation (%) |
Compression Deformation (%) |
Tear Strength (kn/m) |
Size(mm) | Remarks |
| EPDM-10 | Black/Red/White | 100±15 | ≥100 | ≥200 | ≤3.1 | ≥0.5 | 1000*2000*60 | |
| EPDM-10Z | Black/Red | 100±15 | ≥100 | ≥200 | ≤3.1 | ≥0.5 | 1000*2000*60 | Fire retardant |
| EPDM-20 | Black | 85±15 | ≥100 | ≥200 | ≤3.1 | ≥0.5 | 1000*2000*30 |
The difference between EPDM ,NBR and CR rubber foam:
| Comparison of rubber foam performance parameters | |||
|
Performance |
EPDM Rubber Foam |
NBR Rubber Foam |
CR Rubber Foam |
|
Aging resistance |
good |
poor |
good |
|
electrical insulation |
very good |
poor |
poor |
|
preservative |
good |
general |
good |
|
Impact elasticity |
good |
general |
-- |
|
Adhesion properties |
poor |
good |
-- |
|
Oil resistance |
no |
very good |
good |
|
Wear resistance |
good |
good |
-- |
|
Heat resistance |
very good |
good |
good |
|
Cold resistance |
very good |
poor |
poor |
|
Ozone resistance |
good |
-- |
good |
|
Weather resistance |
very good |
general |
very good |
|
Flame resistance |
no |
-- |
good |
|
Acid resistance |
good |
good |
general |
|
Alkali resistance |
good |
good |
good |
